China Factory CE Approved Linkable LED Batten Linear Luminaire IP54 LED Batten Fitting

Product Features

1. New design slim shape LED batten light;

2. 600mm, 1200mm, 1500mm size;

3. Wide power 14W to 70W;

4. High efficacy 130lm/W output;

5. Tridonic brand driver AC220-240V input voltage;

6. Easy installation surface mounted batten light;

7. On/Off, Emergency, CCT, Motion Sensor, Dimming options.

Send email to us Download as PDF

Product Detail

Product Tags

we are able to supply top quality items, aggressive price and greatest buyer assistance. Our destination is “You come here with difficulty and we offer you a smile to take away” for China Factory CE Approved Linkable LED Batten Linear Luminaire IP54 LED Batten Fitting, Welcome all customers of property and abroad to go to our organization, to forge a fantastic long run by our cooperation.
we are able to supply top quality items, aggressive price and greatest buyer assistance. Our destination is “You come here with difficulty and we offer you a smile to take away” for IP54 Batten Fitting, Linkable Batten Light, We’re seeking the chances to meet all the friends from both at home and abroad for the win-win cooperation. We sincerely hope to have long-term cooperation with all of you on the bases of mutual benefit and common development.
Features

This is a new type of batten light developed on the basis of our led batten fitting. The appearance of this LED batten light is more beautiful and gives users a new feeling. The luminous body of the lamp adopts an all-plastic design, which can meet the requirements of IP54 protection level, and the base is still made of aluminum alloy material with spraying surface treatment. LED Batten is mainly used to replace traditional fluorescent lamps and LED lamps, so the market demand is large and can be used in all lighting places. This kiind of LED batten light plays a very important role in our life, as it is popular and favored by people, the data shows, there is over 60% market share compare with other lights.

Technical Specification

Model No.	Size (cm)	Power (W)	Input Voltage (V)	CCT (K)	Lumen (lm)	CRI (Ra)	PF	IP Rate	Warranty
BA005-06C014	60	14	AC220-240	3000-6500	1680	>80	>0.9	IP54	5 Years
BA005-12C028	120	28	AC220-240	3000-6500	3360	>80	>0.9	IP54	5 Years
BA005-12C038	120	38	AC220-240	3000-6500	4560	>80	>0.9	IP54	5 Years
BA005-15C035	150	38	AC220-240	3000-6500	4560	>80	>0.9	IP54	5 Years
BA005-15C055	150	55	AC220-240	3000-6500	6600	>80	>0.9	IP54	5 Years
BA005-18C060	180	60	AC220-240	3000-6500	7200	>80	>0.9	IP54	5 Years
BA005-18C070	180	70	AC220-240	3000-6500	8400	>80	>0.9	IP54	5 Years

Dimension

Model No.	A(L=mm)	B(W=mm)	C(H=mm)
BA005-06C014	600	55	58
BA005-12C028/38	1200	55	58
BA005-15C038/55	1500	55	58
BA005-18C060/70	1800	55	58

Application

LED Batten, LED batten light, batten light, compact design with Tridonic driver, cost-efficient, emergency, DALI, sensor and dimming functions available. Widely apply to the general lighting and indoor car parks, industries, shops, offices, schools, factrories, warehouses etc.
